• splicing outputs with resolution up to 2560×1536@60hz

• support user-define output resolutions 2.6million
• multi-machine synchronous cascade
• support synchronous transition of audio and video

• fade-in and fade-out transition between any signals

• two-channel output, able to complete pip and pop display
• support 1080p full-screen monitoring output
• 2pcs led sending cards built-in ability
• gathering usage records and engineering lock
• navigational settings, easy to be used without training

professional av ports

standard u2 has 6-channel video input:hdmi×1，dvi×1， vga×2，cvbs×2；dvi loop×1。

in particular, ks800 is equipped with 4-channel stereo input and 1-channel audio (the video signals can be specified for synchronous switching).

splicing modes

the two outputs of u2 output different parts respectively to form a complete picture and realize seamless splicing on the led diplay, able to support the maximum 2560×1536 resolution.
copy mode

the two output ports of u2 output uniform picture. it is easy to drive two identical screens. when driving a single screen, it can also be relatively easy to connect the sending cards.

pbp display
u2 can support pbp to achieve pip and pop display or can be used to control two screens different in size.

all input signals of u2 can support fade-in and fade-out transition.

using this function , you can know the use condition of machine any time.

engineering lock

u2 support engineering lock function, and could set working hours. after the scheduled time is reached, it is required to enter the unlock code to use.

in use time, if failed to unlock timely, the device will be locked, and no other operations could be conducted except entering unlock code. the device has no output during locking process.
