u3 enjoys two splicing outputs and 1 pre-monitoring output. with 2.6 mega-pixel user-defined output for a single port in the copy mode, it allows the user to change the aspect ratio and refresh rate of the resolution freely.

multi-format signals processing
u3 is compatible with a variety of input signals : dvi×1, hdmi×1, vga×2, cvbs×2, sdi×1 and expansion slot×1.
u3 enables the simultaneous display of three windows on a single screen.the size location and hierarchical relationship of each window can be adjusted independently.

4k processing accommodating
4k signal input terminals including hdmi 1.4 and dual link dvi,u3 enables an input resolution up to 4096×2160, conveniently realizing uhd display of large led screens!

images and texts overlay
u3 is able to generate independent images and texts overlay layer. the user is allowed to overlay pictures or characters on the signal image conveniently with the kystar control software . the overlaid contents can be stored in the equipment.

multi-screen combination and special-shaped splicing
u3 can not only display 3 windows on a screen, but control 3 led screens simultaneously as well, each of which can display independently or be combined into a complete image. besides, pixel pitch of such screens can be different.

whether in case of a signal or a preset, u3 is capable of seamless transition, without any blackout, glimmer or delay in the process; besides, u3 owns over ten transition effects for choice by the user, adaptable for different applications.

ethernet control
u3 can be compatible with kystar  management software via ethernet or serial communication. users can configure parameters on u3 through management software, adjust window layout, complete special effects switching, set up scheduled tasks etc.

ethernet monitoring and preview
via ethernet, users can not only configure the parameters of u3, but achieve monitoring and preview through the kystar management software in real time.

there’re three modes when using the local monitor & preview output of u3:
1. monitor the outputs, showing the same image with the display.
2. preview the inputs, showing 6 inputs images in the same time.
3. monitor and preview in the same time.

transparency adjusting and edge feathering
in order to integrate the different layers of image well, u3 can change the transparency of  each windows or achieve edge feathering effect.

independent brightness control
u3 can adjust the brightness of each inputs independently so that the user can improve the quality of the specific image without influence to the others.
