single machine can control up to 12 screens

01

w12 supports 12 hdmi signal outputs. it can control up to 12 units of splicing screen, and it can also control 8 independent screens.









screen color calibration

02

w12 can independently adjust the color of each output, which can reduce the color difference between each screen.









output ports mapping

03

using w12 for video wall splicing screen, users don't need to consider the physical position and logical position of each screen unit when connecting the screens to w12.

users can directly adjust the logical position through the device or kystar software, and then the video wall can display the image correctly.









signal/preset seamless switching

04

when switching between signals or presets of screen layout, w12 supports seamless switching with broadcast-level fade-in and fade-out special effect. there will be no blank screen or delay during the switching process.









real-time visualized operation

05

w12 can be controlled by kystar control software. users can monitor the input and output signals on the software through the gigabit ethernet and  finish

real-time editing.









8-layer arbitrary display

06

single w12 can support up to 8 layers from the same or different signals to be displayed at the same time. these layers can be displayed across screens and be arranged arbitrarily.









8 mixed-signal inputs

07

w12 supports 8 dvi-u input interfaces. with the corresponding interface adapter, each channel of input can be compatible with dvi, hdmi, vga, cvbs.









视频输入信号

类型

数量



dvi-u

8

·最大支持分辨率为1920×1200@60hz,向下兼容

·支持dvi/hdmi/vga/cvbs

·兼容hdmi1.3及以下版本,edid版本1.3

视频输出信号

类型

数量



dvi-d(24 1)

12

·支持常见输出分辨率从1024×768@60hz到1920×1080@60hz

·支持60hz/50hz/30hz输出帧率

功能说明

拼接输出

·12个输出口支持任意形式拼接模式,如:3×4、2×6等

8画面输出

·同时在屏幕上呈现8个或8个以下的画面,这些画面可以来自不同或相同的输入信号

·每个画面均可自由缩放、布局,画面之间可相互叠加

画面回显

·使用kystar控制软件可以在计算机上实时获取ks5000的信号画面,包括输入信号以及输出信号

特效切换

·信号切换时,用户可选择淡入淡出特效或快速直切

输出口颜色校正

·支持输出口颜色校正,解决lcd/dlp屏幕色差问题

盲插

·支持输出口映射,十二路输出口可任意插线

工程锁

·可设置工作时间,到达预约时间后需输入解锁密码才可使用

其他

上位机控制方式

rs232/rj45以太网

尺寸(mm)

66(高)×432(长)×256(深)

重量(kg)

4

输入电源

100-240vac,47-63hz,≤2a

工作环境

温度0-40℃;湿度0-95%

保修期

2年免费维修,终身维护
