the most load up to 230 million pixels

01

ks9000 supports up to 90 channels of dvi output or 15 channels of 4k output and the most load up to 230 million pixels. the maximum width is 360000 pixels , and maximum height is 180000. multi machine cascade can realize infinite resolution extension









flexible and stable hardware architecture

02

ks9000pro has a fpga-based modular hardware architecture that all the inputs and outputs module can be customized.

the maximum number of inputs is 90. there are multiple signals to be selected including hdmi2.0/1.4/1.3, dp1.2, dvi, vga, sdi, cvbs.

the maximum number of outputs is 90. the output can be configured as dp1.2 or hdmi2.0 or dvi.

besides, ks9000pro supports multiple power redundancy backup.









crossint splicing technology

03

ks9000pro supports kystar crossint splicing technology, it can effectively eliminate the phase difference between different splicing modules, so as to avoid sub-pixel dislocation during image splicing.









up to 120 windows display

04

ks9000pro can display 120 windows at the same time, which can easily complete multiple screen control and multiple windows arbitrary layout display.









seamless switching

05

ks9000pro supports fade-in and fade-out seamless switching of signals and presets, without blank or delay during the process.









visualized operation in real time

06

equipped with the optional echo module, ks9000pro can enable users to monitor the input signal and output signal pictures through the software via the gigabit network, and configure the parameters in real time .









wireless operation

07

ks9000pro can be controlled by kystar app installed on smartphone or tablet wirelessly.
