features:

01

1.31 million with two network ports

stereo audio input

stable hardware

data readback repair





1.31 million with two network ports

02
s2 supports two network port outputs, and a single card can complete the loading of 1.31 million pixels on the display, with a maximum width of 4000 pixels and a maximum of 2000 pixels.





stereo audio input

03
s2 supports one stereo audio input, and can be used with the multi-function card mf630 to achieve audio transmission.





stable hardware

04
s2 not only selects high-quality components, all connectors are high-standard gold-plated parts, and supportive designs such as power protection are added to ensure the true gold quality of the hardware.

•moreover, the s2 has undergone strict high and low temperature and pulse group detection before leaving the factory to ensure that the product is in the most stable state.



data readback repair

05
s2 supports data readback and repair functions.

•using the readback configuration function, users can quickly read the correct configuration parameters from the receiving card when replacing the sending card, without having to reconfigure the parameters.

•using the configuration retransmission function, when the user replaces the receiving card, this function can help retransmit the configuration stored in the device to complete the system repair without reconfiguring the parameters.



year of production: 2020

supports full-color, dual-color and single color led display

(supports full color led screen, two color & 1 color)

max supports 2048 * 640 pixels

control multi-displays, realizing displays

combination, synchronous display, and independent play



panel description









serial number

function description



j

signal running state indicator



k

two gigabit ports, lan1 and lan2 ports



l

audio input interface



m

usb control terminal for pc upper computer control sending card



n

dvi input interface



o

jp1, 5v direct plug terminal, providing 5v voltage



p

jp2, 4p straight needle white seat, providing 5v voltage



q

j11, small 4p interface, providing 5v voltage



r

pci slot, providing 5v voltage







port specification

input port

type

number

specifications

dvi

1

dvi-d input, support custom input resolution signal

audio

1

3.5mm audio input interface





output port

type

number

specifications

lan

2

gigabit network output port, receiving card





control port

type

number

specifications

usbtype-b

1

usb control port can control sending card with pc software





j3 big 4p power supply interface definition

pin

1

2

3

4

definition

vcc

gnd

gnd

nc





j13 small 4p power supply interface definition

pin

1

2

3

4

definition

vcc

vcc

gnd

gnd
