six-channel video signal input

01

ls4pro supports six-channel hd video signal input, including dvi×1, hdmi×1, vga×2, cvbs×2.

at the same time ,ls4pro support four audio inputs and one audio output .it supports video and audio synchronous switching.

(in addition, usb and hdmi inputs support audio signal)









four ethernet ports with 4.8 million pixels

02

ls8 is equipped with eight ethernet port outputs, the maximum resolution is up to 4.8 million pixels. the maximum horizontal resolution is 3840 pixels , and maximum vertical resolution is 1536 pixels .









multi-machine cascade splicing

03

ls8 supports frame synchronization technology, multiple machines can work together by using dvi-loop interface and realize  seamless splicing to control high resolution screens.









seamless switching with fade-in and fade-out

04

ls8 supports fade-in and fade-out signal switching, without blank screen during the process.









two windows display

05

ls8 supports dual-window display. two signals of the same one or different ones can be arranged arbitrarily on the screen to achieve display effects such as split screen, screen overlay, etc.









configure screen without computer

06

ls8 can store the project file information in advance. users can complete the cabinet mapping of the led screen according to the guidance through the navigation menu without a computer.









date-read-back and easy recovery

07

with the data-read-back function, users can quickly get the correct configuration parameters from the receiving card when replacing the controller.

with the easy recovery function, when the user changes the receiving card, ls8 can resend the configuration which stored in the device , so as to complete the system recovery without reconfiguring the parameters.
