k2 is equipped with 2 groups of dvi output that are back-up to each other. each group has 4 dvi outputs that can be spliced together to achieve the resolution of 9.6 million pixels. the maximum horizontal resolution is 16,000 pixels and the maximum vertical resolution is 8,000 pixels.

k2 supports 6 digital signal inputs: dp * 2, dvi * 2, hdmi * 1 and sdi * 1. both of the dp inputs support 4k * 2k @ 60hz or 8k * 1k @ 60hz uhd resolution.

inputs of k2 support edid customized editing, which enables dp signal to support the resolution of 8k *1k@60hz.

k2 supports more than ten kinds of switching effects that can achieve seamless switching between different signals or even between different presets.

k2 built-in visual editing system, through usb , users can observe the current playing screen and all input signals in real time, and complete the wysiwyg layout operation.

in addition, hero 1000 supports pre-editing. users can visually edit layout and playback content in preview mode, and then play and push after confirmation.

k2 can capture the output image and store it in the device as the background image. when the normal playing signal gets out of order, the background image can be automatically displayed on the screen as backup content.

users can also select other videos or pictures which be already saved in k2 as backup content.

k2 can designate any signal as the backup of the current signal. when the signal gets out of order , the backup signal can be switched on automatically.

 with kir (kommander intelligent recognition) technology, k2 can work with kommander media sever to form a highly reliable backup system.
