k1pro-9479威尼斯

k1pro is equipped with 2 groups of dvi output that are back-up to each other. each group has 4 dvi outputs that can be spliced together to achieve the resolution of 9.6 million pixels. the maximum horizontal resolution is 16,000 pixels and the maximum vertical resolution is 8,000 pixels.

k1pro supports  simultaneous display of any four signals. it can complete display 4 windows on a screen or control 4  led screen at the same time.

inputs of k1pro support edid customized editing, which enables dp signal to support the resolution of 8k *1k@60hz.

k1pro supports more than ten kinds of switching effects that can achieve seamless switching between different signals or even between different presets.

k1pro supports scene preview editing ， which enables users to observe the current displaying content and all the input signals in real time, that can visually edit layout and display content in the preview mode, and activate it after confirming.

k1pro can make special effects processing for signals such as transparency, edge feathering, and chroma key matting to make the display effect more creative.

k1pro can capture the output image and store it in the device as the background image. when the normal playing signal gets out of order, the background image can be automatically displayed on the screen as backup content.

users can also select other videos or pictures which be already saved in k1pro as backup content.

k1pro can designate any signal as the backup of the current signal. when the signal gets out of order , the backup signal can be switched on automatically.

 with kir (kommander intelligent recognition) technology, k1pro can work with kommander media sever to form a highly reliable backup system.
