kls8pro-9479威尼斯

kystar hdr enhancement image enhancement

01
ls8pro supports kystar hdr enhancement (k-hdr) technology, which can perform real-time dynamic optimization according to the image content, widen the dynamic range of the image, enable ordinary sdr images to obtain hdr display effects, and solve the less painful points of hdr video sources in the industry. bring a stunning visual experience.





input preview and output monitoring

02
complete input and output monitoring on one display

connected to the monitor through the dvi-monitor output port, you can preview all input signals and monitor the output signal screen at the same time.



10 ethernet ports, 5 million pixel load

03

the ls8pro is equipped with 10 network port outputs, supporting a maximum of 5 million pixel loading, a maximum width of 8000 pixels, and a maximum of 4000 pixels.

the led display can be driven directly without an external sending controller.





dual 4k signal input

04

the kls8pro supports a total of 6 digital signal inputs: dp×1, dvi×4, hdmi×1,  and dp and hdmi  supports 3840×2160@30hz ultra high definition resolution.







ethernet monitoring & control in real time

05

kls8pro supports ethernet echo, and can be visualized through the kystar management software.







seamless transition with effects

06

whether in case of a signal or a preset, kls8pro is capable of seamless transition, without any blackout, glimmer or delay in the process; besides, kls8pro owns over ten transition effects for choice by the user, adaptable for different applications.







special effects

07
chroma key cutout and transparency adjustment.

all layers of ls16pro can realize chroma key cutout function, and support arbitrary transparency adjustment to realize various creative displays.



hot backup of inp ut signals

08

users can specify the backup signal for signal source . if current signal goes wrong, the system will automatically detect and call the backup signal immediately. and if the signal returns to normal, the system will transfer back to the original signal intelligently. building parallel system with this function, the reliability of scene can be guaranteed efficiently.











images and text overlay

09
kls8pro is able to generate independent images and texts overlay layer. the user is allowed to overlay pictures or characters on the signal image conveniently with the kystar control software . the overlaid contents can be stored in the equipment.
