two in one video controller





six-channel video signal input

02

ls2 support six-channel hd video signal input  ,including:dvi×1,hdmi×1 ,vga×1 ,cvbs×2,usb×1。

at the same time ,ls2 support two-channel audio input and one channel audio output .it support video and audio synchronization switch. (in addition, usb and hdmi support audio transmission).





dual network port with 1.3 million pixels

03

ls2 have two network port output , the maximum load up to 1.31 million pixels. the maximum width is 3840 pixels , and maximum height is 1536 pixels . and the network port output also support synchronously transmit audio signal.





seamless switching with fade-in and fade-out

04

ls2 supports fade-in and fade-out signal switching, without blank screen during the process.









usb disk play support

05

with a built-in usb player , ls2 can play pictures, videos and audio documents from the usb disk automatically. with the software of kommander pe , it can realize flexible offline playing function .









hardware setting screen, no need computer

06

ls2 can store the project file information in advance. users can complete the cabinet mapping of the led screen according to the guidance through the navigation menu without a computer.









date-read-back and easy recovery

07

with the data-read-back function, users can quickly get the correct configuration parameters from the receiving card when replacing the controller.

with the easy recovery function, when the user changes the receiving card, ls2 can resend the configuration which stored in the device , so as to complete the system recovery without reconfiguring the parameters.









复合(bnc输入)

输入接口数量

(number of inputs)

2

支持标准

(supported standards)

pal/ntsc

信号电平

(signal level)

1vpp±3db (0.7v video 0.3v sync )

75欧姆端结

hdmi输入

输入接口数量

(number of inputs)

1

支持标准

(supported standards)

edid/ddc2b

信号电平

(signal level)

1vpp±3db  (0.7v video 0.3v sync )

 75欧姆端结

vga(db15输入)

输入接口数量

(number of inputs)

1

接口形态

标准db15插座

支持分辨率

(supported standards)

vga-uxga

信号电平

(signal level)

r、g、b、hsync、vsync:0 to1vpp±3db  (0.7v video 0.3v sync ) 75欧姆端结

black level: 300mv sync-tip: 0v

dvi输入

输入接口数量

(number of inputs)

1

输入接口形态(connector)

标准dvi-d插座

支持分辨率

smpte: 625/25 pal, 525/29.97

ntsc, 625/50p pal, 525/59.94p

ntsc, 1080p60,1080i50, 1080i59.94/60, 720p50 和 720p59.94/60

vesa: 800×600@60hz,1024×768@60hz,1280×768@60hz,1280×1024@60hz,1600×1200@60hz

信号电平

tmds电平,单像素输入,165mhz带宽

标准

dvi 1.1

usb输入

输入接口数量

(number of inputs)

1

支持标准

(supported standards)

u盘、sd卡等输入

信号电平

(signal level)

1vpp±3db  (0.7v video 0.3v sync )

 75欧姆端结

网口输出

输出接口数量

4

接口形态

千兆网口

附属

“ce”标准认证说明

bs en 55013:2001 a1:2003 a2:2006

bs en 61000-3-2:2006 a2:2009

bs en 6100-3-3:2008

bs en 55020:2007

bs en 6006:2002 a1:2006 a11:2008

电脑及中控系统控制

rs232

电源

85-264v 2a iec-3电源接口

工作环境

0°c~45°c

储藏环境

10% to 90%

产品质保

2年有限质保
